| Introductions:
- State-of-art technology makes x-Field Indirect Diagnostic/Laser Lenses Larger，more precision, higher image contrast, less bothersome reflections and maximizes visible and diode laser transmission.
- Impact, Chip and Fracture Resistant.
- Extra Large view field and Extra clear Vision make x-Field different.
- State of the art double aspheric design and manufacturing techniques.
- Superior optical material, which is Larger, more precision, higher image contrast, less reflections and maximizes visible
- They are guaranteed for life time against breakage, coating abrasion and defects in material and workmanship.
- Hydrophobic coating, which repels water, smudges and dust, making cleaning easier.
- The 90D standard is also available with a large, 32mm holding ring.
- Lenses also available in colored mount.
Parameters:
| Lens Name |
Used with |
Image Mag. |
Laser spot Mag. |
Static Field of View |
Dynamic Field of View |
Focal Length |
Working distance(mm) |
Clear Aperture(mm) |
| 20D |
BIO |
2.97x |
0.34x |
48 |
na |
50 |
47 |
51 |
| 78D |
Slit Lamp |
0.93x |
1.07x |
82 |
108 |
12.8 |
8 |
30 |
| 90D |
Slit Lamp |
0.76x |
1.33x |
85 |
121 |
11.1 |
6 |
21 |
|
|
