- Printing Method
Direct thermal printing
- Resolution
325 dpi
- Gradation
8 bits (256 levels) processing
- Picture elements
Digital: 1,280 x 2,560 dots Video NTSC: 720 x 504 dots Video PAL: 720 x 604 dots
- Picture area
Digital: 100 x 200 mm (3 7/8 x 7 7/8 in) (Max) STD Video NTSC: 94 x 73 mm (3.7 x 2.87 in), Video PAL: 94 x 71 mm (3.7 x 2.8 in) (WIDE1) SIDE Video-NTSC: 96 x 124 mm (3.78 x 4.88 in), Video-PAL: 96 x 127 mm (3.78 x 5 in) (WIDE1)
- Paper Size
Paper width of 110 mm (4 3/8 inches)
- Printing Time
High-speed mode: Approx. 2 seconds/image (at standard setting) (1,280 x 960 dots)
Normal speed mode: Approx. 3.8 seconds/image (at standard setting) (1,280 x 960 dots)
- Interface
Hi-Speed USB connector (USB 2.0): type C (for data receiving) (x1)
VIDEO IN: BNC type (NTSC or PAL composite video signals) (1)
- Printer Driver SW
Microsoft Windows 10, 11
- Picture requirements
AC 100 V to 240 V, 50/60 Hz
- Input Current
0.75 A to 0.5 A
- Operating Temperature
10 ℃ to 40 ℃ (50 ℉ to 104 ℉)
- Operating Humidity
20% to 80% (no condensation allowed)
- Storage and transport temperature
–20 ℃ to +60 ℃ (–4 ℉ to +140 ℉)
- Storage and transport humidity
20% to 90% (no condensation allowed)
- Dimensions (W*H*D)
154 × 88 × 208 mm (6 1/8 × 31/2 × 81/4 in)
- Mass
2.0 kg (4 lb 6.5 oz) (printer only)
- Supplied Accessories
Thermal head cleaning sheet (1)
CD-ROM (1)
Before Using this Printer (1)
Service Contact List (1)
Thermal Print Media
UPP-110HG/SET(1)
Information for customers in Europe (1)
- EC directive
* The values for dimensions are approximate. This product is distributed to the US and EU as a medical device and satisfies product safety standards (e.g. IEC 60601-1)**.
** For more details, please contact your nearest Sony sales office or an authorized dealer.
