| Applications:
The products have high degree of standardization, beautiful appearance, and also have the feature about rational structure, easy to use, clarity of visual field and quality stability. And these products also are the general Equipment for medical, research, and teaching.
Specifications:
1. Eyepieces
Category |
Magnification |
Diameter of view-field(mm) |
Remark |
Wide field eyepiece |
WF10X |
ф18 |
|
|
WF16x |
ф11 |
|
2. Objectives
Category |
Magnification |
Numerical aperture |
Working distance |
Remark |
Achromatic
objectives |
4X |
0.10 |
37.5 |
|
10X |
0.25 |
7.613 |
|
40X(s) |
0.65 |
0.632 |
|
100X(s.oil) |
1.25 |
0.198 |
Spring |
3. Total magnification
Objectives |
tube coefficient |
Total magnification |
Eyepiece 10X |
Objectives 16X |
4X |
1X |
40X |
64X |
10X |
100X |
160X |
40X |
400X |
640X |
100X |
1000X |
1600X |
4. Mechanical tube length: 160mm
5. ABBE condenser, NA=1.25
6. Filter diameter: 32mm
7. Coarse/fine focal range:20mm
8. Stage size:X-Y:132*140mm
Longitudinal movement range: 70mm
Horizontal movement range: 30mm
9. Monitor size: 10 inch
|
